DAB-82MP - PUMP SURFACE MOUNTED JET WITH PRESSURE SWITCH 60L/MIN 47M 0.60KW 240V

Code: 701445

Print
Product Code
DAB-82MP
Find Your Nearest Store
Product Documents Find a Service Agent
Technical Specifications
Brand DAB Pumps
Product Type Pressure System
Bar 4.7
Suitable For Clean Water
Approval Approved For Drinking Water
Flow Range Category a. 0 - 99 L/min
Flow Rate (L/min) 60
Hp 0.8
kPa 476
Kilo Watts 0.6
Head Range Category b. 40 - 59 m
Max Head (m) 47
Port Size Inlet 1" BSPF inlet
Port Size Outlet 1" BSPF outlet
Powered Electric
Taps 6
Volts 240
Warranty (months) 24
Watts 600
Description
0.60kW, 0.8hp, 240V, max hd 47m, max flow 60L/m, 6 taps Ports 1” BSPF In, 1” BSPF Out. Includes NRV.
Features
Self Priming Cast Iron Jet Pressure Pumps

2 Year DAB Warranty

Drinking Water Approved
AS/NZS 4020 drinking water approved

AS/NZS 4020 Drinking Water Approved.

Pumps that are AS/NZS 4020 Drinking Water Approved Offer peace-of-mind.

This approval ensures that the pump will not contribute any toxic materials or metals to the liquid being pumped, won’t support the growth of micro-organisms and won’t change the taste or appearance of your water. Read More...
Spare Parts
Code
Part Number
Description
702087
DABSR00010537
ASSEMBLY ACTIVEJ82M-N.6
702135
DABSR00004811
BOARD ACTIVEEI25/30M-N.7
702079
DABSR00008871 12.5UF
CAPACITOR ACTIVEEI30/50M-N.8
702077
DABSR00004002
FAN ACTIVEEI25/30M-N.7
702080
DABSR00004010
IMPELLER ACTIVEJ82M-N.6
702084
DABSR00004017
LOAD PLUG ACTIVEEI25/30M-N.7
702176
DABSR00005131
MOTOR ACTIVEEI30/50M-N.8
702081
DABSR00004011
MOTOR COVER ACTIVEEI25/30M-N.7
702085
DABSR00004018
PLUG ACTIVEEI25/30M-N.7
702076
DABSR00004000
PUMP BODY ACTIVEJ82M-N.6
702119
DABSR00009575
SEAL ACTIVEJ82M
702078
DABSR00004003
SUPPORT ACTIVEJ82M-N.6
